Huba Differential Pressure Switch Range 50 To 500 Pac

Huba Differential Pressure Switch Range 50 To 500 Pac

• Model : 604.9100001
• Range : 50–500 Pa (0.5–5 mbar)
• Max : 75 Mbar (-30T85)
• Max : 50 Mbar (-30T75)
• Maximum Overload at −30°C to +75°C : 75 mbar
• Maximum overload at −30°C to +85°C : 50 mbar
• Medium Temperature : −30°C to +85°C
• Ambient Temperature : −30°C to +85°C
• Made In Switzerland
• Country Of Origin : Switzerland

We Supply High Quality Products of Huba Control Which You May Use to Recover Your Broken Equipment. Our Team of Experts is Ready to Find the Best Cheap Prices For Products of Huba Control-604.9100001 Differenzdruck-Schalter Type 604 in United States.Save Money With World’s High Quality and Low Price Products made by Huba Control.Using Our Professional Services Will Help You Be More Competitive on the Market and it will Save You Time.Our company is Not a Representative of Huba Control, But we are Selling Their Products at Good Prices.We Are Selling Huba Control-604.9100001 Differenzdruck-Schalter Type 604 in United States at competitive prices!During The Past Years we Managed to Develop Enough to Satisfy the Requirements Of Our Customers

• User-Friendly Snap Closure For The Cover
• Cable Entry Aid
• Cable Strain Relief Integrated Into PG11
• Combination Bracket For Vertical Or Horizontal Mounting
• High Adjustment Accuracy Through Individual Scale Engraving Per Switch

Product Feature

Technical Data

• Pressure Measuring Range:0..50 Mbar Relative & Difference
• Sensor Weight:143g

Field Of Application

• Media:Air Neutral Gas
• Medium Temperature:-30..85°C
• Permissible Overload On One Side:75 Mbar-30..75ºC 50 Mbar-30..85ºC

Ambient Condition

• Ambient Temperature:-30…85°C
• Storage Temperature:-40..85°C

Material

• Housing With Media Contact:PC 10% GF
• Measuring Element With Media Contact:Silicone LSR Tempered At 200°C,Outgassing-Free
• Cover With Media Contact:PC

Electrical Data

• Switching Load:5 A at 250 VAC
• Resistive Switching Load:4 A at 30 VDC
• Inductive Switching Load:0.8 A at 250 VAC 0.7 A at 30 VDC
• Switching Load GAR Application:1 A at 250 VAC 0.2 A at 30 VDC
• Contact System:Changeover Switch
• Lifespan:>10000000 Schaltspiele Mechanical

Installation Guide

• Installation Orientationany:Any Recommendation Vertical Pressure Connections Downwards Factory Adjustment Any Recommendation Horizontal Cover Down Switching Points Are Approx 11 Pa Lower Than The Set Scale Value Any Recommendation Horizontal Cover Upward Switching Points Are Approx 11 Pa Higher Than The Set Scale Value

Approval

• UL:MFHX2/8 Or XAAK2/8
• DVGW:According to DIN EN 1854
• Low Voltage Directive:2014/35/EU
• Gas Appliances Directive:2016/426/EU

Applications

• AHU,CRAC,MOBILE HYDRAULIC

Accessories

• Connection Set Straight:For Ventilation Duct Including 2 M Hose Plastic
• Angle Type B
• Combination Bracket Type C
• Snap Ring:For Angle A,B,C Or Direct Mounting For Wall Thickness 1.8…2.1 MM
• Snap Ring:For Angle A,B,C Or Direct Mounting For Wall Thickness 0.8…1.1 MM
• Angle Type A
• Fastening Screw:For Wall Thickness 1-2 MM Screw Length 6 MM Min 2 Screws Required
• Connection Set 90° Angled:For Ventilation Duct Including 2 M Hose Metal
