402.9300021 Huba Control Differential Pressure Transmitter

402.9300021 Huba Control Differential Pressure Transmitter

• • Differential Pressure Transmitter
  • Type – 402
  • Manufacturer – HUBA CONTROL
  • Model – 402.9300021
  • RANGE – 0-10 MBAR
  • OUT – 0.5….4.5 V
  • IN – 12 ( 10.2…. 33 ) V

Product information

Differential Pressure Transmitters of Type 402

• • Attractive Price-Performance Ratio
  • Excellent Synergy Of Membrane Techn
  • ology And Ceramic Elements
  • Special Adapter For DIN Rail Mounting
  • Direct PCB Mounting With Simple Snap System

Technical Data

Product Feature

• • Pressure Measuring Range : 0 … 50 mbar (Relative and Difference)
  • Response Time : <10 ms
  • Load Change : <10 Hz
  • Sensor Weight : 28 g

Field Of Application

• • Media : Air; Neutral Gases
  • Medium Temperature : 0 … 70 °C (Non-Freezing Media)
  • Permissible Overload On One Side : 100 Mbar
  • Bursting Pressure At Room Temperature : 200 Mbar
  • Bursting pressure at 70°C : 150 Mbar

Ambient Condition

• • Ambient Temperature : 0 … 70 °C
  • Storage Temperature : -30 … 70 °C

Material

• • Housing With Media Contact : Polycarbonate (PC); Polyamide (PA)
  • Membrane With Media Contact : Silicone
  • Measuring Element With Media Contact : Ceramic Al2O3 (96 %)

Electrical Data

• • Output Pressure : 0,5 … 4,5 V
  • Supply Voltage : 10,2 … 33 VDC
  • Permissible Load : >15 kOhm (Against GND)
  • Current Consumption : <8 mA
  • Inverse-Polarity Protection : Mechanically guaranteed
  • IP Protection Class : IP 00
  • Electrical Connection : Printed Circuit Board Assembly (Solderable Pins On The Print Side); Printed circuit board assembly (Mounted And Soldered On Adapter); RAST 2.5 Connector

Approval

• • EMC Compatibility : The Product Is Intended Exclusively For Installation In Appliances That Fulfil The Requirements Of The EC Directives. CE Certification Is The Responsibility Of The Customer.

Installation guide

• • Installation Orientation : Pressure Connections Downwards;Pressure Connection P1 Top
  • Assembly : Snap-On Mounting On Printed Circuit Board (Max. 1.6 MM Thickness); Adapter; Screw Mounting With Bracket.

Applications

• • VAB SYSTEMS
  • ERV
  • MOBILE HYDRAULIC
  • INDUSTRIAL AUTOMATION

Accessories

• RAST 2.5 Connector : With Cable; 110 CM; 3-Pole
• Fastening Screw : For Wall Thickness 1 – 2 MM; Screw Length 6 MM (Min. 2 Screws Required)
• Calibration Certificate
• Mounting Bracket
• Mounting Plate Complete For Mounting Rail TS 35
• Fastening Screw : For Wall Thickness 4.1 – 6 MM; Screw Length 10 MM (Min. 2 Screws Required)
