GEMS 3100B0010G01B000 Pressure Transmitter 0-10 Bar

GEMS 3100B0010G01B000 Pressure Transmitter 0-10 Bar

Product Information

GEMS Model 3100 Is a Compact,Heavy-Duty OEM Pressure Transmitter Designed For Accurate And Reliable Pressure Measurement in Demanding Industrial Applications.It Uses Sputtered Thin-Film Sensing Technology And Rugged All-Welded Stainless-Steel Construction.The Specified 3100B0010G01B000 Configuration is Suitable For Compound/Negative-Pressure Measurement With a 4–20 mA Output.
Technical Data

• Brand: GEMS
• Model: 3100
• Part No.: 3100B0010G01B000
• Pressure Range: 0 to 10 Bar
• Pressure Type: Compound/Gauge
• Output: 4–20 mA
• Circuit: 2-Wire
• Supply: 8–30 VDC
• Accuracy: ±0.25% FS
• Sensing Technology: Sputtered Thin Film
• Enclosure: IP67
• Response Time: 1 ms
• Compensated Temperature: -40°C to +125°C
• Wetted Parts: 17-4PH Stainless-Steel Diaphragm,304 Stainless-Steel Fittings
• Weight: Approximately 35 g

Product Features

• ±0.25% FS Accuracy
• 4–20 mA Industrial Output
• 2-Wire Configuration
• Sputtered Thin-Film Sensing
• All-Welded Stainless-Steel Construction
• IP67 Environmental Protection
• Reverse-Wiring Protection
• High Vibration Resistance
• Compact Design
• Long-Term Stability
• RoHS Compliant

Field Of Application

Suitable For Hydraulic Systems,Compressors,Pumps,Industrial Machinery, HVAC/R Equipment,Process-Control Systems,Automation,OEM Machinery, Vacuum/Compound Pressure Monitoring And Industrial Instrumentation.
Ambient Condition

Operating And Storage Temperature: Approximately -40°C to +125°C. IP67 Protection Helps Protect The Transmitter Against Moisture And Humidity.
Material

• Diaphragm: 17-4PH Stainless Steel
• Fittings: 304 Stainless Steel
• Construction: All-Welded Stainless Steel

Electrical Data

• Output: 4–20 mA
• Circuit: 2-Wire
• Supply: 8–30 VDC
• Maximum Loop Resistance: (Supply Voltage − 8) × 50 Ω
• Reverse-Wiring Protected

Installation Guide

Confirm The Pressure Range And Pressure-Port Configuration Before Installation.Mount The Transmitter Securely Without Excessive Mechanical Force.Connect The 4–20 mA Loop According To The Applicable Wiring Diagram And Use An Appropriate 8–30 VDC Supply.Check All Connections For Leakage And Verify The Output Signal Before Commissioning.
Approval

The Model 3100 Series is CE and UL Approved,RoHS Compliant And IP67 Rated,Subject To The Exact Configuration.
Accessories

Compatible Accessories May Include Mating Electrical Connectors,Pressure Adapters,Seals,Cables,Mounting Hardware And Process-Connection Accessories.The Exact Accessory Should Match The Transmitter Configuration.

Additional Information:

• Item Code: GEMS 3100B0010G01B000 Pressure Transmitter 0-10 Bar
