DWYER MAGNEHELIC® DIFFERENTIAL PRESSURE GAUGE
- Range: 0–180 Inch of Water Column (In. W.C.)
- Model No.: 2180
Product / Service Description
Dwyer Magnehelic® Differential Pressure Gauge is Designed for accurate measurement of Positive Pressure, Negative Pressure (Vacuum), And Differential Pressure. The Gauge Operates Without Electrical Power and is suitable for air and compatible non-combustible gases.
Specification / Additional Details
- Brand: Dwyer
- Series: 2000 Magnehelic®
- Model: 2180
- Range: 0–180 Inch of Water Column (In. W.C.)
- Type: Differential Pressure Gauge
- Accuracy: ±2% Full Scale
- Display: Analog Dial
- Power Requirement: No Electrical Power Required
- Enclosure Protection: IP67
- Process Connection: 1/8″ Female NPT High & Low Pressure Connections
- Suitable Media: Air and compatible non-combustible gases
- Mounting: Panel Mount / Surface Mount / Flush Mount options
- Operating Temperature: Approximately -6.7°C to 60°C
- Pressure Indication: Positive, Negative and Differential Pressure
Application
- HVAC Systems
- Air Filter Monitoring
- HEPA Filter Monitoring
- AHU & FCU Systems
- Clean Rooms
- Pharmaceutical Industries
- Hospitals
- Laboratories
- Blower Pressure Monitoring
- Fan Pressure Monitoring
- Duct Pressure Measurement
- Building Pressure Monitoring
- Industrial Ventilation Systems
Model Range Examples
| Model | Range (In. W.C.) |
|---|---|
| 2000-00N | 0.05–0–0.20 |
| 2000-00 | 0–0.25 |
| 2000-0 | 0–0.50 |
| 2001 | 0–1 |
| 2002 | 0–2 |
| 2003 | 0–3 |
| 2004 | 0–4 |
| 2005 | 0–5 |
| 2006 | 0–6 |
| 2008 | 0–8 |
| 2010 | 0–10 |
| 2012 | 0–12 |
| 2015 | 0–15 |
| 2020 | 0–20 |
| 2025 | 0–25 |
| 2030 | 0–30 |
| 2040 | 0–40 |
| 2045 | 0–45 |
| 2050 | 0–50 |
| 2060 | 0–60 |
| 2080 | 0–80 |
| 2100 | 0–100 |
| 2120 | 0–120 |
| 2150 | 0–150 |
| 2160 | 0–160 |
| 2180 | 0–180 |
| 2200 | 0–200 |
| 2250 | 0–250 |
| 2300 | 0–300 |
| 2400 | 0–400 |
| 2500 | 0–500 |
