3100B0200S01B Setra Pressure Transmitter 0-200 Bar

Product Information

Setra Model 3100B0200S01B is an Industrial OEM Pressure Transmitter Designed For Accurate And Reliable Measurement Of Pressure Up To 0–200 Bar.It Uses Thin-Film Sensing Technology And is Suitable For Industrial,Hydraulic,Irrigation,Pump,Compressor And Process-Monitoring Applications.The Specified Configuration Uses 4–20 mA Output,8–30 VDC Supply And 1/4″ NPT Process Connection
Technical Data

  • Brand: Setra Systems
  • Series: Model 3100
  • Part No.: 3100B0200S01B
  • Pressure Range: 0–200 Bar
  • Output: 4–20 mA
  • Supply Voltage: 8–30 VDC
  • Accuracy: ±0.25% FS
  • Pressure Type: Gauge/Sealed Gauge configuration as ordered
  • Process Connection: 1/4″ NPT Male
  • Electrical Connection: Industrial DIN
  • Enclosure: IP67
  • Operating Temperature: -40°C to +125°C
  • Compensated Temperature: -40°C to +125°C
  • Response Time: Approximately 1 ms
  • Wetted Parts: 17-4PH Stainless-Steel Diaphragm And 304 Stainless-Steel Fittings
  • Construction: All-Welded Stainless Steel
  • Weight: Approx. 35 g For Standard Model 3100 Construction


Product Features:


• High Accuracy And Fast Response
• Rugged Industrial Construction
• 4–20 mA Standard Analog Output
• Wide DC Supply Range
• IP67 Protection
• Excellent Vibration Resistance
• Compact OEM Design
• Reliable Long-Term Operation
• Suitable For High-Pressure Applications
• Easy Integration With PLC And Control Systems

Field Of Application:


Hydraulic Machinery,Hydraulic Power Packs,Pumps,Booster Systems, Compressors,Irrigation Systems,Water Treatment Plants,HVAC Equipment, Refrigeration Systems,Industrial Automation,Process Control, Manufacturing Machinery and OEM Equipment


Ambient Condition:


Designed For Industrial Environments With An Operating Temperature Range Of Approximately -40°C to +125°C.IP67 Protection Helps Protect Against Dust And Water Ingress When Correctly Installed


Material:


Stainless-Steel Construction With Stainless-Steel Wetted Components, Suitable For Demanding Industrial Pressure Applications


Electrical Data:


2-Wire 4–20 mA Current Output With 8–30 VDC Supply.Connect The Transmitter According To The Specified Wiring Diagram And Maintain Correct Polarity


Installation Guide:


Install On a Compatible 1/4″ NPT Pressure Port.Use Suitable Sealing Material Where Required.Do Not Exceed The Rated Pressure Range. Connect The 4–20 mA Loop To a Suitable DC Supply And Control System. Check For Leakage And Verify The Output Signal After Installation


Approval:


Applicable Configurations Provide IP67 Protection And Relevant EMC/RoHS Compliance.Check The Product Label And Exact Datasheet For Configuration-Specific Approvals


Accessories:


Mating Connector,Cable,Pressure Fittings,Thread Adapters,24 VDC Power Supply,PLC/Display Interface And Calibration Equipment.
